Level relay PZ-828 (single-level DIN-rail mounting 35mm 230V AC 16A 1contact IP20) F&F EA08.001.001 Evroautomatika F&F

"PZ" series level control relay DIN-rail mounting. Designed for monitoring and maintaining a set level of conductive liquids in tanks, pools, water towers, etc. and controlling electric motors of pumping units. Upon power-on, the relay enters operating mode after 2 seconds. Sensor connection terminals are galvanically isolated from the power circuits. Depending on the liquid in which the sensor is placed, the sensitivity of the input stages of the device changes. For normal operation, after installation, the sensitivity should be adjusted using the regulators on the front panel ("100" - increase, "1" - decrease). Sensor included. Sensor connection wire can be extended up to 50 meters. Features of the PZ-828 level relay: maximum load current - 16 A; contacts - 1NO/NC;
