Time relay 06-6s 12V AC-DC EMAS RZ1A2C06S-1

RZ1A2C06S-1 Time relay (0.6-6 sec, ON and OFF delay), 1NC+1NO, 12V AC/DC TECHNICAL INFORMATION Mechanical endurance: not less than 10,000,000 operations Electrical endurance: not less than 100,000 operations Operating temperature: min./max. -5/+40 °C Protection degree: IP00 Maximum switching frequency: 6,000 operations per hour (at partial load) Rated voltage, Ue: 12V AC/DC Rated coil voltage: 1.5VA AC; 1 W DC Rated current, le: 5A Max. voltage: 250V AC Max. switching capacity: 1250VA Operating frequency: 50-60Hz Operating power: max. 2VA AC / min. 2W DC setting accuracy: ±2% Voltage effect: < 1 % Max. response time: ≤ 100 ms Voltage range: (0.85-1.1)*Ue Standard contact material: silver/nickel Weight: 60±3g RZ1A series analog time relays • 9 time intervals • Panel mounting via a special flexible connecting clamp or DIN-rail mounting 35mm using an 8-pin terminal block type RS1PO8 • With ON and OFF delay • Ensures minimum motor downtime during malfunctions • Small dimensions • Relay status is monitored by LEDs on the front panel ON and OFF delay. From the moment power is applied to the relay, the cycle time begins, and after the set time t1 expires, the contact closes, resulting in a change of signal at the terminal.
