Евроавтоматика F&F
Time relay PO-415 16A 230V 1 contact IP20 off-delay/control contact DIN-rail mount F&F EA02.001.018 Euroautomatika F&F
SKU: EA02.001.018
ETIM: EC001439
1961 ₽
Price list (incl. VAT):
1961 ₽
Available July 31
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to default_city | |
|---|---|---|---|---|---|
|
Remote warehouse
Available
|
8 | шт | July 31 | July 31 |
Select a warehouse to order
"PO" series time relay
DIN-rail mounting.
Designed to maintain device operation after the control contact opens for a set period of time, provided that the duration of the control signal is greater than the on-delay. For example, in ventilation systems, bathrooms, etc., when the light is turned on by a switch, the fan will turn on with a delay; after turning off the light, the fan will turn off after a set period of time.
Operating principle
As a result of closing the control contact S for a time exceeding t, the relay contacts 11,12 close. Opening the control contact S triggers the countdown of the set time, after which the relay operation ceases.
Features:
control input;
supply voltage 230 V AC;
on-delay 0/1...5 min;
off-delay 1...15 min;
contact - 1NO/NC (16 A).
| Remote control possible | No |
| Height | 90 мм |
| Depth | 65 мм |
| Time range at | 900 с |
| Time range from | 60 с |
| Number of delayed outputs, changeover contact | 1 |
| Rated control supply voltage Us AC at 50 Hz up to | 250 В |
| Rated control supply voltage Us AC at 50 Hz from | 230 В |
| Switch-on current type | Alternating current (AC) |
| Switch-on delay function | No |
| Switch-off delay function | Yes |
| Star/delta function | No |
| Width | 18 мм |
