Time relay RV-03 3x8A 100-264V AC/DC 3NO/NC IP20 multifunctional 3-channel. 9 operating modes with START inputs, time delay range 0s-99h 59min; 3 mounting modes on DIN-rail F&F EA02.001.026 Euroautomatika F&F
SKU: EA02.001.026
ETIM: EC001439
7,035 ₽
Analogues by specifications
"RV" series time relay
DIN-rail mounting.
Designed for switching electrical circuits (up to 3 independent circuits K1, K2, K3) with pre-set time delays t1, t2 and t3 for use in automation circuits.
Operating modes
Mode F1.1...F1.3 - "Pulse formation via K1. Turn-on delay for load via K2 and K3";
Mode F2.1...F2.3 - "Pulse formation via K1. Turn-off delay for load via K2 and K3";
Mode F3.1...F3.3 - "Pulse formation via K1. Turn-on delay via K2. Turn-off delay via K3";
Mode F4.1...F4.3 - "Turn-on delay via K1...K3";
Mode F5.1...F5.3 - "Turn-off delay via K1...K3";
Mode F6.1...F6.3 - "Group cyclic operation via K1...K3";
Mode F7.1...F7.3 - "Cyclic sequential switching of three loads";
Mode F8.1...F8.3 - "Cyclic sequential switching of two loads via K2, K3";
Mode F9.1...F9.3 - "Three-channel relay with independent program execution for each channel"
Features:
three-channel;
digital indication;
9 operating modes;
three memory cells for each mode;
supply voltage 100...264 V AC/DC;
time delay range 0 s... 99 h 59 min;
contact - 3NO/NC (3x8 A).
Height
90 мм
Depth
65 мм
Time range at
356400 с
Time range from
Please provide the text you would like me to translate. с
Number of delayed outputs, changeover contact
3
Rated control supply voltage Us AC at 50 Hz up to
264 В
Rated control supply voltage Us AC at 50 Hz from
100 В
Rated control supply voltage Us DC up to
264 В
Rated control supply voltage Us DC from
100 В
Switch-on current type
AC/DC
Switch-on delay function
Yes
Switch-off delay function
Yes
Flashing function starts on pulse, fixed time
Yes
Flashing function starts with pause, fixed time
Yes
Pulse shaping function
Yes
Width
52 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
23498 ₽
ПЭО прочее Time relay VL-56 110V 50Hz 0.1-10min A8011-76911519 PEO other
SKU: A8011-76911519
6403 ₽
FINDER 1-function modular timer (AI) 24-240V AC/DC 1CO 16A 22.5mm time adjustment 0.05s-10days IP20 railway version FINDER 831102400000T
SKU: 831102400000T
20104 ₽
ВНИИР Time relay RSV-17-3 1…100s 24V pos. trans. assigned VNIIR A8120-76919089
