Эра
1-way socket SP Era12 12-2105-13 16A IP20 16AX 250V 2P mechanism bronze Era B0019336
SKU: Б0019336
ETIM: EC000125
217 ₽
Get back 2 ₽ in points
Analogues by specifications
Era 12 series flush-mounted socket, mechanism color bronze 12-2105-13. Rated characteristics 16A 250V. Made of polycarbonate, equipped with automatic terminals for fast and reliable fixation of cable cores in the mechanism. Pair terminals ensure loop connection. Mounting into the back box is performed both on lugs and on screws. Frames are sold separately. Era 12 frames: 1 gang 12-5001-xx, 2 gangs 12-5002-xx, 3 gangs 12-5003-xx, 4 gangs 12-5004-xx, 5 gangs 12-5005-xx. Era 12 Satin frames: 1 gang 12-5101-xx, 2 gangs 12-5102-xx, 3 gangs 12-5103-xx, 4 gangs 12-5104-xx, 5 gangs - 12-5105-xx (xx - color code: 01-white, 02-ivory, 03-aluminum, 04-champagne, 05-anthracite, 06-black, 07-alder (bleached oak-satin), 08-cherry, 09-oak, 10-wenge, 11-pine, 21-yellow, 22-orange, 23-red, 24-ochre, 25-burgundy, 26-lime, 27-green, 28-light blue, 29-blue).
Special power supply
No special power supply required
RAL number (similar)
8014
Supplied with plug (connector)
No
Material type/grade
Thermoplastic
Phase selection
No (without)
Device height
75 мм
Device depth
42 мм
Differential current protection
No
For heavy duty (per VDE)
No
Overvoltage protection
No
Protective surface coating
Untreated
Design
Without protective contact
Number of seats
1
Number of modules (modular system)
0
Number of switchable outlets
0
Material
Plastic
Extraction mechanism
No
Halogen-free
Yes
Rated voltage
250 В
Rated current
16 А
Labelling surface
No
Suitable for ingress protection IP
IP20
Transparent
No
With built-in USB charger
No
With power switch
No
With lock
No
With orientation lighting
No
With hinged cover
No
With illumination (mains voltage indication)
No
With low-current fuse
No
With central insert
No
Symbols/indication
Without marking
With shutters (touch protection)
No
Mounting method
Flush-mounted
Connection method
Pluggable terminal
Fastening type
Clamp mounting/Screw mounting
Surface type
Matte
Switch-off function
No
Color
Bronze
Frequency at
60 Гц
Frequency from
50 Гц
Device width
75 мм
