Legrand
Socket Outlet 1-Gang Flush Mounted Inspiria 16A IP44 250V 2P+E with Shutters with Cover German Standard Mechanism Anthracite IEK 673743 Legrand (IEK Group)
SKU: 673743
ETIM: EC000125
4,246 ₽
Get back 42 ₽ in points
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
Inspiria grounded socket with protective cover and integrated safety shutters for flush mounting, IP44 protection rating, color "Anthracite", rated current 16A, voltage ~250V, maximum power 3680 W, screw terminals. Used for connecting single-phase electrical consumers to an AC network in buildings with grounded wiring (with a protective conductor). Designed for installation in high-humidity areas. Equipped with integrated shutters that protect children and other users from electric shock.
Special power supply
No special power supply required
Antibacterial
No
Material type/grade
Thermoplastic
Device height
89 мм
Device depth
48 мм
Differential current protection
No
Contact protection
Yes
Overvoltage protection
No
Protective surface coating
Untreated
Insulated installation
No
Design
With grounding (protective) contact
Number of seats
1
Number of switchable outlets
0
Number of phases
1
Front cover
In the housing
Material
Plastic
Extraction mechanism
No
Minimum depth of recessed mounting box
32 мм
Halogen-free
Yes
Rated voltage
250 В
Rated current
16 А
Rated current
16 А
Labelling surface
No
Suitable for ingress protection IP
IP44
Transparent
No
With built-in USB charger
No
With power switch
No
With lock
No
With orientation lighting
No
With hinged cover
Yes
With illumination (mains voltage indication)
No
With signal lamp
No
With low-current fuse
No
With through-channel function
Yes
With central insert
No
Symbols/indication
Without designation
With shutters (touch protection)
Yes
Mounting method
Flush-mounted (in plaster)
Connection method
Screw terminal
Fastening type
Clamp mounting/Screw mounting
Surface type
Matte
Impact resistance
IK04
Colour
Anthracite
Color
Anthracite
Frequency at
60 Гц
Frequency from
50 Гц
Device width
84 мм
