Розетка 16А 250В 2P+E с 2хUSB 5В-3А защ. шторки Эра12 бел. 12-4109-01 ЭРА Б0047840
SKU: Б0047840
ETIM: EC000125
3215 ₽
Preorder
Grounded socket with USB and shutters, Era 12 series, recessed installation, mechanism color white 12-4109-01. Rated characteristics 16A 250V/3A-5V. Made of polycarbonate. Installation into the back box is performed both on lugs and on screws. Frames are sold separately. Era 12 frames: 1 gang 12-5001-xx, 2 gangs 12-5002-xx, 3 gangs 12-5003-xx, 4 gangs 12-5004-xx, 5 gangs 12-5005-xx. Era 12 Satin frames: 1 gang 12-5101-xx, 2 gangs 12-5102-xx, 3 gangs 12-5103-xx, 4 gangs 12-5104-xx, 5 gangs 12-5105-xx (xx - color code: 01-white, 02-ivory, 03-aluminum, 04-champagne, 05-anthracite, 06-black, 07-alder (white oak-satin), 08-cherry, 09-oak, 10-wenge, 11-pine, 21-yellow, 22-orange, 23-red, 24-ochre, 25-burgundy, 26-lime, 27-green, 28-light blue, 29-blue).
| RAL number (similar) | 9010 |
| Material type/grade | Thermoplastic |
| Differential current protection | No |
| Overvoltage protection | No |
| Number of seats | 1 |
| Material | Plastic |
| Minimum depth of recessed mounting box | 45 мм |
| Halogen-free | Yes |
| Rated voltage | 250 В |
| Rated current | 16 А |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| With power switch | No |
| With orientation lighting | No |
| With hinged cover | No |
| With illumination (mains voltage indication) | No |
| Symbols/indication | Without marking |
| With shutters (touch protection) | Yes |
| Mounting method | Flush-mounted |
| Connection method | Pluggable terminal |
| Fastening type | Clamp mounting/Screw mounting |
| Surface type | Shiny |
| Color | White |
