Эра
Socket 2-way SP Era12 12-2108-03 16A IP20 250V 2x2P+E Schuko with shutter alum. Era B0036444
SKU: Б0036444
ETIM: EC000125
530 ₽
Get back 5 ₽ in points
Analogues by specifications
Double socket with grounding and shutters Era 12 series flush-mounted, color aluminum 12-2108-03. Rated characteristics 16A 250V. Made of polycarbonate, equipped with automatic terminals for fast and reliable fixation of cable cores in the mechanism. Paired terminals provide loop connection. Mounting in the back box is performed via both claws and screws. Frames are purchased separately. Era 12 frames: 1 gang 12-5001-xx, 2 gang 12-5002-xx, 3 gang 12-5003-xx, 4 gang 12-5004-xx, 5 gang 12-5005-xx. Era 12 Satin frames: 1 gang 12-5101-xx, 2 gang 12-5102-xx, 3 gang 12-5103-xx, 4 gang 12-5104-xx, 5 gang 12-5105-xx (xx - color code: 01-white, 02-ivory, 03-aluminum, 04-champagne, 05-anthracite, 06-black, 07-alder (bleached oak-satin), 08-cherry, 09-oak, 10-wenge, 11-pine, 21-yellow, 22-orange, 23-red, 24-ochre, 25-bordeaux, 26-lime, 27-green, 28-light blue, 29-blue).
Special power supply
No special power supply required
RAL number (similar)
7001
Supplied with plug (connector)
No
Material type/grade
Thermoplastic
Phase selection
No (without)
Device height
75 мм
Device depth
42 мм
Differential current protection
No
For heavy duty (per VDE)
No
Overvoltage protection
No
Protective surface coating
Untreated
Design
With SCHUKO earthing contact
Number of seats
2
Number of modules (modular system)
0
Number of switchable outlets
0
Material
Plastic
Extraction mechanism
No
Halogen-free
Yes
Rated voltage
250 В
Rated current
16 А
Labelling surface
No
Suitable for ingress protection IP
IP20
Transparent
No
With built-in USB charger
No
With power switch
No
With lock
No
With orientation lighting
No
With hinged cover
No
With illumination (mains voltage indication)
No
With low-current fuse
No
With central insert
No
Symbols/indication
Without marking
With shutters (touch protection)
Yes
Mounting method
Flush-mounted
Connection method
Pluggable terminal
Fastening type
Clamp mounting/Screw mounting
Surface type
Matte
Switch-off function
No
Color
Aluminum
Frequency at
60 Гц
Frequency from
50 Гц
Device width
75 мм
