Systeme Electric ArtGallery series quick-connect terminal mechanism in basalt color for a single socket with grounding, shutters, and cover is suitable for 250 V networks, 16 A current.
A solution for lovers of matte surfaces in interiors, which are pleasant to touch.
New quick-connect terminal technology allows for 25% faster installation.
Faceplates are made of high-quality ABS plastic, resistant to scratches and UV radiation.
Best industrial design (based on the results of the Minpromtorg award 2023).
| Special power supply | No special power supply required |
| RAL number (similar) | 7021 |
| Antibacterial | No |
| Supplied with plug (connector) | No |
| Material type/grade | Thermoplastic |
| Device height | 71 мм |
| Device depth | 43.5 мм |
| Differential current protection | No |
| For heavy duty (per VDE) | No |
| Contact protection | Yes |
| Overvoltage protection | No |
| Protective surface coating | Untreated |
| Round protective grounding contact (pin) | Yes |
| Insulated installation | Yes |
| Design | With SCHUKO earthing contact |
| Number of active contacts (round) | 2 |
| Number of active contacts (flat) | 0 |
| Number of seats | 1 |
| Number of modules (modular system) | 0 |
| Number of switchable outlets | 0 |
| Number of phases | 1 |
| Material | Plastic |
| Extraction mechanism | No |
| Minimum depth of recessed mounting box | 45 мм |
| Halogen-free | Yes |
| Rated voltage | 250 В |
| Rated current | 16 А |
| Rated leakage current | 0 мА |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| Transparent | No |
| With built-in USB charger | No |
| With power switch | No |
| With lock | No |
| With orientation lighting | No |
| With hinged cover | Yes |
| With illumination (mains voltage indication) | No |
| With signal lamp | No |
| With low-current fuse | No |
| With through-channel function | No |
| With central insert | No |
| Symbols/indication | Without marking |
| With shutters (touch protection) | Yes |
| Mounting method | Flush-mounted |
| Connection method | Pluggable terminal |
| Fastening type | Clamp mounting/Screw mounting |
| Surface type | Matte |
| Impact resistance | IK03 |
| Color | Black |
| Frequency at | 60 Гц |
| Frequency from | 50 Гц |
| Device width | 71 мм |
