Socket outlet ArtGallery 16A with earthing and shutters quick-connect terminals mechanism lotus SE GAL001345S Systeme Electric

SKU: GAL001345S

ETIM: EC000125

673 ₽

Price list (incl. VAT): 673 ₽

Available August 4

Order multiple: 5

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Transit warehouse Available	5	шт	August 4	August 4

Select a warehouse to order

Description Specifications Reviews

Special power supply	No special power supply required
RAL number (similar)	9003
Antibacterial	No
Supplied with plug (connector)	No
Material type/grade	Thermoplastic
Device height	71 мм
Device depth	43.5 мм
Differential current protection	No
For heavy duty (per VDE)	No
Contact protection	Yes
Overvoltage protection	No
Protective surface coating	Untreated
Round protective grounding contact (pin)	Yes
Insulated installation	Yes
Design	With SCHUKO earthing contact
Number of active contacts (round)	2
Number of active contacts (flat)	0
Number of seats	1
Number of modules (modular system)	0
Number of switchable outlets	0
Number of phases	1
Material	Plastic
Extraction mechanism	No
Minimum depth of recessed mounting box	45 мм
Halogen-free	Yes
Rated voltage	250 В
Rated current	16 А
Rated leakage current	0 мА
Labelling surface	No
Suitable for ingress protection IP	IP20
Transparent	No
With built-in USB charger	No
With power switch	No
With lock	No
With orientation lighting	No
With hinged cover	No
With illumination (mains voltage indication)	No
With signal lamp	No
With low-current fuse	No
With through-channel function	No
With central insert	No
Symbols/indication	Without marking
With shutters (touch protection)	Yes
Mounting method	Flush-mounted
Connection method	Pluggable terminal
Fastening type	Clamp mounting/Screw mounting
Surface type	Matte
Impact resistance	IK03
Color	White
Frequency at	60 Гц
Frequency from	50 Гц
Device width	71 мм
