КЭАЗ
Switch Disconnector VR32-35 V71250 250A UKhL3 KEAZ 103390
SKU: 103390
ETIM: EC000216
6427 ₽
Price list (incl. VAT):
6427 ₽
Available August 11
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Remote warehouse | |||||
|
Transit warehouse
Available
|
14 | шт | August 11 | clarifying | |
|
РЦ Тверь
Available
|
22 | шт | August 12 | clarifying | |
Select a warehouse to order
3-pole switch-disconnector for rated current 250 A, equipped with a removable handle.
| Version as switch-disconnector | No |
| Version as main switch | No |
| Number of auxiliary NO contacts | 0 |
| Number of auxiliary break contacts | 0 |
| Number of poles | 3 |
| Design | Built-in fixed-mounted device |
| Maximum rated operational voltage Ue AC | 660 В |
| Motor drive optional | No |
| Independent trip unit | No |
| Rated power in AC-23 operating mode, 400 V | 100 кВт |
| Rated power in AC-3 mode, 400 V | 100 кВт |
| Rated power at AC-3, 400 V | 100 кВт |
| Rated continuous current Iu | 250 А |
| Reversing design | No |
| With interlock | No |
| Ingress protection (IP) of front side | IP00 |
| Main electrical circuit connection type | Screw connection |
| Control element type | Lever |
| Conditional rated short-circuit current Iq | 14 кА |
| Colour of control elements | Black |
