IEK
Cable gland MG 25 conductor diameter 13-18mm IP68 IEK YSA20-15-25-68-K02
SKU: YSA20-15-25-68-K02
ETIM: EC000441
3,904 ₽
Get back 39 ₽ in points
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
MG type cable glands are installed at cable entry and exit points in switchgear enclosures. They are designed to protect conductors from mechanical damage and protect the assembly itself from dust and moisture penetration at the entry and exit points.
The range of MG type cable glands allows for selecting products for cable diameters from 4 mm to 45 mm.
Glass fibre reinforced
No
Explosion-proof verified
No
Material type/grade
Polyamide
Box hole diameter
25
Thread length
12.4 мм
For armoured cable
Yes
For gas explosion hazardous areas
No
For cable diameter to
18 мм
For cable diameter from
13...18 мм
For dust explosion protection zone (EU ATEX directives)
No
Kink protection
No
Protective surface coating
Untreated
Design
Str./straight
Flat cable gland
No
Tension compensator
No
Material
Plastic
Multi-layer sealing zone
No
Nominal thread size in inches NPT/Gas pipe thread
Other
Nominal metric/PG thread size
25.0
Jaw size
33 мм
Split or separable gland
No
With locknut
Yes
IP protection rating
IP68
Resistance to ignition
650
Operating temperature to
100 град.C
Operating temperature from
-40...100 град.C
Thread type
Metric thread
Sealing type
O-ring
Impact-resistant
No
Colour
Black
Color
Black
Thread pitch
1.5 мм
