IEK
Cable gland PGM 16 metal conductor diameter 10-14mm IP68 IEK YSA50-14-22-68-K23
SKU: YSA50-14-22-68-K23
ETIM: EC000441
319 ₽
Get back 3 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Designed for introducing wires and cables into electrical switchgear to protect conductors from mechanical damage and protect the assembly itself from the penetration of dust and moisture at the entry point.
The cable gland consists of a body (1), a seal (2), a sealing nut (3), a washer (4), and a locking nut (5).
The seal and washer are made of neoprene.
The body, sealing nut, and locking nut are made of nickel-plated brass. The cable gland is installed using a pipe (gas) wrench.
Glass fibre reinforced
No
Material type/grade
Brass
Box hole diameter
22.28
Thread length
9.2 мм
For armoured cable
No
For gas explosion hazardous areas
No
For cable diameter to
14 мм
For cable diameter from
10...14 мм
For dust explosion protection zone (EU ATEX directives)
No
Kink protection
No
Protective surface coating
Nickel-plated finish
Design
Str./straight
Flat cable gland
No
Material
Metal
Sealing ring material
Neoprene
Nominal thread size in inches NPT/Gas pipe thread
Other
Nominal metric/PG thread size
22.3
With locknut
Yes
IP protection rating
IP68
Operating temperature to
100 град.C
Operating temperature from
-40...100 град.C
Thread type
PG
Sealing type
O-ring
Impact-resistant
No
Colour
Natural colour
Color
Natural colour
Thread pitch
1.41 мм
