Cable gland PGM 48 metal conductor diameter 37-44mm IP68 IEK YSA50-44-59-68-K23
SKU: YSA50-44-59-68-K23
ETIM: EC000441
1949 ₽
Price list (incl. VAT):
3118 ₽
Preorder
Кратность заказа: 3
Designed for introducing wires and cables into electrical switchgear to protect conductors from mechanical damage and protect the assembly itself from the penetration of dust and moisture at the entry point.
The cable gland consists of a body (1), a seal (2), a sealing nut (3), a washer (4), and a locking nut (5).
The seal and washer are made of neoprene.
The body, sealing nut, and locking nut are made of nickel-plated brass. The cable gland is installed using a pipe (gas) wrench.
| Glass fibre reinforced | No |
| Material type/grade | Brass |
| Box hole diameter | 59.3 |
| Thread length | 13.8 мм |
| For armoured cable | No |
| For gas explosion hazardous areas | No |
| For cable diameter to | 44 мм |
| For cable diameter from | 37...44 мм |
| For dust explosion protection zone (EU ATEX directives) | No |
| Kink protection | No |
| Protective surface coating | Nickel-plated finish |
| Design | Str./straight |
| Flat cable gland | No |
| Material | Metal |
| Sealing ring material | Neoprene |
| Nominal thread size in inches NPT/Gas pipe thread | Other |
| Nominal metric/PG thread size | 59.3 |
| With locknut | Yes |
| IP protection rating | IP68 |
| Operating temperature to | 100 град.C |
| Operating temperature from | -40...100 град.C |
| Thread type | PG |
| Sealing type | O-ring |
| Impact-resistant | No |
| Color | Natural colour |
| Colour | Natural colour |
| Thread pitch | 1.59 мм |
