Seismic base for CQE N enclosures, WxDxH 1000x600x100 RAM block R5ZE1061SYB DKC

The seismic plinth is designed for use in conjunction with a seismic reinforcement kit for installing floor-standing enclosures of the CQE N series in seismic hazard zones, including NPP and HPP facilities. The material of the elements is 4 mm thick steel. Simultaneous use of the seismic kit and the seismic plinth provides reinforcement of the enclosure frame, compliance with vibration strength for mechanical execution group M40, and seismic resistance up to 9 points on the MSK-64 scale at an installation height of up to 70 m. The galvanized bushings of the kit ensure a rigid connection between the lower seismic corners of the cabinet and the seismic plinth, significantly increasing the overall stiffness of the structure. The components are compatible exclusively with CQE N series enclosures. Dimensions WxDxH: 1000x600x100 mm.
