R5ZE881SYB AO "Dielectric Cable Systems"

The seismic base is intended for use with a seismic reinforcement kit for installing CQE N series floor-standing enclosures in seismically active zones, including NPP and HPP facilities. Element material – 4 mm thick steel. Simultaneous use of the seismic kit and the seismic base ensures reinforcement of the enclosure frame, compliance with vibration resistance according to mechanical execution group M40, and seismic resistance up to 9 points on the MSK-64 scale at an installation height of up to 70 m. The galvanized bushings of the kit ensure a rigid connection of the lower seismic corners of the cabinet with the seismic base, significantly increasing the overall rigidity of the structure. Components are compatible exclusively with CQE N series enclosures. Dimensions WxDxH: 800x800x100 mm.
