VRU Shield ShR11-73514 IP54 Electrospectr _VSHR514

Distribution cabinets 01 series ShR11 (ShRS1) are designed for receiving and distributing electrical energy. Cabinets are designed for rated currents up to 400A and rated voltage up to 380V three-phase AC frequency 50 Hz and with protection of outgoing lines by fuses NPN2-60 (up to 6A), PN2-100 (up to 100A), PN2-250 (up to 250 A), PN2-400 (up to 400A). Wire and cable entry and exit are provided from the bottom and top of the cabinet. ShR-11, unlike ShRS-1 cabinets, has additional application possibilities. For example, in ShR-11-73511...73517 cabinets, PN2-400 fuses are installed at the input, and in 73518...73523 cabinets, two inputs are provided. Otherwise, the design and diagrams of these cabinets are identical. In cabinets with 5 outgoing lines, the width is 500mm.
