IEK
N "neutral" busbar on two angle insulators ShNI-8x12-22-U2-S IEK YNN10-812-22C2-K07
SKU: YNN10-812-22C2-K07
ETIM: EC000329
8,610 ₽
Get back 86 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 10 шт
Analogues by specifications
Busbars with insulator type SHNI are designed for electrical and mechanical connection of neutral, protective, and phase conductors. Structurally, SHNI busbars are made of a brass busbar mounted on a plastic insulator or in an insulator made of self-extinguishing plastic.
Normal operating conditions for the busbars are:
- ambient temperature from –40 to +50 C;
- average relative humidity not more than 90%.
Fastening screws
M5
Height
29.3 мм
Height
29.3 мм
Depth
15...29 мм
Design
Other
Climatic version
U2
Number of cable outlets
22
Number of busbars
1
Maximum conductor cross-section
25/10 кв.мм
Material
Brass
Busbar purpose
N-neutral
Rated voltage
400 В
Rated current In
125 А
Busbar cross-section
8x12
Mounting method
Screw, for mounting panel
Operating temperature from
-40...50 град.C
Surface type
Untreated
Type version
With 2 angle insulators
Insulator colour
Blue
Width
165...193 мм
