DIN rail terminal in enclosure cross-module SHNK 2x11 L+PEN Era B0062830
SKU: Б0062830
ETIM: EC001894
898 ₽
Get back 8 ₽ in points
Analogues by specifications
ERA cross-module enclosure neutral bars are used for the electrical and mechanical connection of neutral, protective, and phase conductors in electrical panels and switchgear. The product consists of brass bars insulated from each other with screw terminals, installed in a dielectric cross-module enclosure. The enclosure is flame-retardant as it is made of polyamide with flame retardants added.
This design ensures safe installation and operation thanks to a transparent front cover that protects against accidental contact and facilitates visual inspection of connections.
Ease of installation is achieved through universal mounting with the possibility of installation on a 35 mm DIN rail and a mounting panel. Rapid installation is ensured by special size markings and the corresponding number of conductors for connection applied to the front cover.
The use of neutral bars in a cross-module enclosure allows:
- to combine all incoming and outgoing neutral, phase, or grounding conductors into one common group,
- to reduce the number of conductors in the panel, which simplifies its maintenance,
- to save space and easily place new elements,
- to ensure a stable and durable connection.
Product design features:
- Material: L56 brass
- Cross-section: 8x12 mm
- Rated current In: 125 A
- Diameter of the hole for connecting incoming conductors: ø 6, 7, 5 mm
- Diameter of the hole for connecting outgoing conductors: ø 4.5 mm
- Clamping screws are made of galvanized steel and have a rounded contact part, which prevents cutting and damage to the connected conductors
Height
87 мм
Depth
50 мм
Number of terminals per pole
11
Number of modules
5
Number of poles
2
Maximum design current
125 А
With neutral busbar n
Yes
With PE busbar
Yes
Flexible conductor with ferrule cross-section up to
6 кв.мм
Flexible conductor cross-section with ferrule from
1.5 кв.мм
Rigid conductor cross-section to
16 кв.мм
Rigid conductor cross-section from
6 кв.мм
Width
101 мм
