EKF
Stockholm Socket outlet mechanism 1-gang with earthing 16A screw terminals black with shutters EKF EZR16-028-20
SKU: EZR16-028-20
ETIM: EC000125
234 ₽
Price list (incl. VAT):
439 ₽
Available July 31
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
7790 | шт | July 31 | July 31 |
Select a warehouse to order
Single socket EKF Stockholm series with grounding and shutters will be an excellent solution for a stylish room when connecting devices. The shutters open when simultaneous pressure is applied to both holes and prevent the penetration of foreign objects, ensuring additional safety. Made of polycarbonate resistant to ultraviolet radiation. The product must be supplemented with a frame.
| Special power supply | No special power supply required |
| RAL number (similar) | 9 005 |
| Wireless local area network | No |
| Material type/grade | Thermoplastic |
| Device height | 74 мм |
| Device depth | 54 мм |
| Differential current protection | No |
| For heavy duty (per VDE) | No |
| Contact protection | Yes |
| Overvoltage protection | No |
| Protective surface coating | Untreated |
| Round protective grounding contact (pin) | Yes |
| Insulated installation | Yes |
| Design | With earthing contact |
| Number of seats | 1 |
| Number of switchable outlets | 1 |
| Number of phases | 1 |
| Material | Plastic |
| Extraction mechanism | No |
| Minimum depth of recessed mounting box | 54 мм |
| Cable trunking installation | No |
| Halogen-free | Yes |
| Rated voltage | 230 В |
| Rated current | 16 А |
| Support ring | Yes |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| Transparent | No |
| With built-in USB charger | No |
| With power switch | No |
| With lock | No |
| With orientation lighting | No |
| With hinged cover | No |
| With illumination (mains voltage indication) | No |
| With signal lamp | No |
| With low-current fuse | No |
| With through-channel function | No |
| With central insert | No |
| Symbols/indication | Without marking/printing |
| With shutters (touch protection) | Yes |
| Mounting method | Internal / concealed |
| Connection method | Screw clamp/terminal |
| Configuration type | Mechanism with cover plate |
| Fastening type | Snap-on fixing |
| Surface type | Matte |
| Impact resistance | IK01 |
| Color | Black |
| Frequency at | 60 Гц |
| Frequency from | 50...60 Гц |
| Device width | 74 мм |
