Stockholm 2-gang socket mechanism ground 16A automatic terminals white with shutter protection EKF EYR16-128-10
SKU: EYR16-128-10
ETIM: EC000125
320 ₽
Get back 3 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Double socket EKF Stockholm series with grounding and shutters will be an excellent solution for a stylish room when connecting devices. The shutters open when both holes are pressed simultaneously and prevent the penetration of foreign objects, ensuring additional safety. Made of polycarbonate resistant to ultraviolet radiation. Automatic self-clamping terminals simplify and speed up product installation. The product must be supplemented with a frame.
Special power supply
No special power supply required
RAL number (similar)
9 010
Antibacterial
No
Wireless local area network
No
Material type/grade
Thermoplastic
Device height
74 мм
Device depth
54 мм
Differential current protection
No
For heavy duty (per VDE)
No
Contact protection
Yes
Overvoltage protection
No
Protective surface coating
Untreated
Round protective grounding contact (pin)
Yes
Insulated installation
Yes
Design
With earthing contact
Number of seats
2
Number of switchable outlets
2
Number of phases
1
Material
Plastic
Extraction mechanism
No
Minimum depth of recessed mounting box
54 мм
Cable trunking installation
No
Halogen-free
Yes
Rated voltage
230 В
Rated current
16 А
Support ring
Yes
Labelling surface
No
Suitable for ingress protection IP
IP20
Transparent
No
With built-in USB charger
No
With power switch
No
With lock
No
With orientation lighting
No
With hinged cover
No
With illumination (mains voltage indication)
No
With signal lamp
No
With low-current fuse
No
With through-channel function
No
With central insert
No
Symbols/indication
Without marking/printing
With shutters (touch protection)
Yes
Mounting method
Internal / concealed
Connection method
Screwless clamp/terminal
Configuration type
Mechanism with cover plate
Fastening type
Snap-on fixing
Surface type
Glossy
Impact resistance
IK01
Color
White
Colour
White
Frequency at
60 Гц
Frequency from
50...60 Гц
Device width
83 мм
