EKF
Construction terminal SMK 222-423 feed-through 3 poles 0.08-4 mm2 EKF PROxima plc-smk-423
SKU: plc-smk-423
ETIM: EC000446
61 ₽
Get back 1% in points
Order multiple: 25 шт
From our own stock you can buy 20 шт in any quantity. Above that — supply on order, in multiples of 25 шт.
Analogues by specifications
Stock by warehouse
EKF connection terminals are designed for connecting and branching copper wires up to 4 mm². The terminals feature increased strength and are designed for multiple use. The tin-plated copper contact part increases the terminal's throughput capacity. SMK terminals ensure simple and fast installation and have a unique design on the Russian market. SMK 222 through terminals are designed for repeated connection of single-core and multi-core copper conductors in AC electrical circuits with a frequency of 50 Hz and voltage up to 400 V. The terminals can be used at temperatures from –40 to +40° C.
Cable diameter at
1.83 мм
Cable diameter from
0.32...1.83 мм
AWG cross-section range to
11
AWG cross-section area range with
28...11
Number of clamps, terminals
6
Rated voltage
400 В
Rated cross-section at
4 кв.мм
Rated cross-section from
0.8...4 кв.мм
Rated current
32 А
Suitable for flexible conductor
Yes
Suitable for stranded conductors
Yes
Suitable for solid conductors
Yes
With contact paste
No
With control lever
Yes
Flexible conductor with ferrule cross-section up to
4 кв.мм
Flexible conductor cross-section with ferrule from
0.08...4 кв.мм
Rigid conductor cross-section to
2.5 кв.мм
Rigid conductor cross-section from
0.08...2.5 кв.мм
Color
Light grey
Colour
Light grey
