Emergency luminaire DPA 5042-3 3h universal IP65 IEK LDPA0-5042-3-65-K01
SKU: LDPA0-5042-3-65-K01
ETIM: EC001957
9778 ₽
Price list (incl. VAT):
11110 ₽
Available August 5
Order multiple: 10
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Transit warehouse
Available
|
168 | шт | August 5 | August 5 | |
|
Manufacturer warehouse
Available
|
480 | шт | August 21 | August 21 | |
|
Manufacturer warehouse
Available
|
55 | шт | August 21 | August 21 |
Select a warehouse to order
DPA 5042 series emergency luminaires are used to mark evacuation exits in premises with high moisture and dust content (IP65), and can also be used to indicate the direction of evacuation (pictograms are not included in the delivery set). The emergency operation of the luminaires is powered by a built-in (non-replaceable) battery. The luminaires feature universal connection (maintained and non-maintained - depending on the circuit). Recognition range is 16 m, power consumption during charging is 5 W. Comply with GOST R IEC 60598-2-22 requirements for emergency lighting.
| Supplied with lamp | Yes |
| Emergency operating time to | 3 ч |
| Emergency operation time from | 3.0 ч |
| Height/depth | 66.0 мм |
| Overall luminance | 1135 |
| Length | 356 мм |
| Length | 356 мм |
| Starting current duration | 35 |
| Battery capacity | 1.8 А.ч |
| Protection against mechanical impact (ball impact) | No |
| Electric shock protection class | Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules. |
| Light distribution class | P |
| Climatic version | UKhL3.1 |
| Number of LEDs | 60 |
| Max. battery charging time | 24 |
| Maximum power | 5.0 Вт |
| Housing material | Plastic |
| Diffuser/lampshade material | Transparent plastic (translucent) |
| Lamp power | 5.0 Вт |
| Rated battery voltage | 4.8 |
| Rated emergency operating time | 3.00 ч |
| Rated voltage up to | 230 В |
| Rated voltage from | 230 В |
| Rated luminous flux | Please provide the text you would like me to translate. лм |
| Suitable for number of light sources | 36 |
| Power consumption | 5.0 кВт |
| Suitable for marking | Sticker/label |
| Inrush current | 0.02 |
| Recognition distance | 28 м |
| With connection to remote switch panel | No |
| Luminous flux in emergency mode | 140 % |
| Power supply system | Self-contained (individual battery) |
| Mounting method | Wall mounting |
| IP protection rating | IP65 |
| Connection diagram | Other |
| Operating temperature from | -10...35 град.C |
| KSS type | D |
| Battery type | NiMH battery (nickel-metal hydride) |
| Lamp type | LED light source |
| Lamp type | LED light source |
| Marking type | Single-sided only |
| Luminaire type | Single-sided |
| Connection diagram type | Maintained |
| Monitoring device | TEST Button |
| Control device | Electronic ballast |
| Housing color | White |
| Colour temperature from | 6500 К |
| Lamp base (holder) | No |
| Frequency (Hz) | 50 Hz |
| Width | 136.0 мм |
