LEDEL
Luminaire L-lego II 250/225/G60/740/L100/05/IKIX-36/220AC IP66 LEDEL LGII225-314-514-18
SKU: LGII225-314-514-18
ETIM: EC001716
53,431 ₽
Get back 534 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Check lead time
Request sent
We will contact you shortly.
No description available
Without dimming
Yes
Supplied with lamp
Yes
Height/depth
220 mm
Operating voltage range
165...430
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
380 mm
Length
380 mm
Heat and frost resistant at
40 °C
Heat and frost resistant from
-60...40 °C
Ignitor
Not required
Colour rendering index
70-79 (class 2A)
Grille design
No (without)
Colour category
Neutral (cool white) 3300-5300 K
Electric shock protection class
I
Fire hazard class
No
Luminous flux ripple coefficient
≤ 1
Power factor
≥ 0.9
Maximum power
225 W
Housing material
Aluminum
Housing material
Aluminum
Reflector material
Without reflector
Lamp power
225 W
Rated voltage up to
220 V
Rated voltage from
230 V
Rated luminous flux
29925 lm
Reflector
No (without)
Ballast included
No
Perforated grille
No
Suitable for lamp power to
225 W
Suitable for lamp power from
- W
Suitable for number of light sources
-
Suitable for emergency lighting
No
Programmable dimming
No
Current type
Alternating current (AC)
With protective cover
No
With protective grille/mesh/screen
No
Light output
Straight
Luminous flux
29925 lm
Light distribution
Deep
Touch dimming
No
Core cross-section
.75 mm²
Special application
No
Mounting method
Suspended
IP protection rating
IP66
Ambient temperature up to
50 °C
Ambient temperature from
-40 °C
Operating temperature from
-60...40 °C
KSS type
G
Lamp type
LED light source
Lamp type
LED light source
Connection type
Terminating
Diffuser type
Multi-lens
Beam angle
60
Light beam angle
Wide beam 41-80 deg
Impact resistance
No (without)
Control device
LED driver
Housing color
No (without)
Light color
White
Color temperature at
4000 K
Colour temperature from
4000 K
Lamp base (holder)
Other
Frequency (Hz)
50 Hz
Width
330 mm
Power supply energy efficiency (ballast, driver, transformer)
A2 BAT
Luminaire energy efficiency
133
