LED luminaire 90 369 ODSP-04-36-4K-LED DSP 36W 4000K 3780lm IP65 1203x75x63 ONLAIT 90369
SKU: 90369
ETIM: EC002892
2,034 ₽
Analogues by specifications
Luminaires are designed for indoor and outdoor lighting. Ideally suited for industrial, commercial premises, and other locations with high humidity and dust levels. Ability to connect in a line (18W - up to 24 pieces, 36W - up to 12 pieces)
- Efficiency up to 106 lm/W
- Through-wiring implemented
- Easy access to terminals for connection
- The luminaire body and frosted diffuser are made of high-impact polystyrene
- Installation type: surface-mounted, suspended
- Wide operating temperature range from -40 to +40 °C
Without dimming
Yes
Supplied with lamp
Yes
Height/depth
63 мм
Length
1203 мм
Colour rendering index
80-89 (class 1B)
Electric shock protection class
Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules.
Built-in luminaire energy efficiency class
A++, A+, A (LED)
Power factor
.95
Maximum power
36 Вт
Housing material
Plastic
Diffuser/lampshade material
Opal plastic
Highest energy efficiency class of replaceable luminaire
A+
Rated voltage up to
265 В
Rated voltage from
170 В
Rated luminous flux
3780 лм
Rated current from
170 мА
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for continuous light lines
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
Yes
Suitable for number of light sources
1
Suitable for emergency lighting
No
Designed for flush mounting
No
Current type
Alternating current (AC)
With motion sensor
No
Light output
Straight
Light distribution
Symmetrical
Special application
Industrial lighting
IP protection rating
IP65
Ambient temperature up to
40 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Light beam angle
Extra wide beam > 80 deg
Control device
LED driver (LED power supply)
Colour temperature from
4000 К
Width
75 мм
Luminaire efficiency
105 лм/Вт
