Innolux
LED luminaire 92 802 ДВО-01-П-30-4К-IP40-Armstrong-A1 CRI90 Innolux 92802
SKU: 92802
ETIM: EC001957
Price on request
Analogues by specifications
Request a price
Request sent
We will contact you shortly.
Construction.
All-metal welded enclosure made of sheet steel, coated with white powder paint. Features a convenient push-in terminal block for connection.
Installation.
Mounts in Armstrong suspended ceilings or other ceilings with an installation size of 595x595 mm, and is also attached to the ceiling or a support surface using hangers (not included in the kit).
Optical part.
Diffusers are made of lighting polymer material, providing uniform soft light.
Light source.
High-efficiency HONGLI 2835 LEDs with a color rendering index >90 are used.
Areas of use.
Administrative and office premises, retail areas, public spaces.
Additional information.
The luminaire is equipped with an emergency power supply unit. Installation of a protective grille is possible
Emergency operating time to
1 h
Emergency operation time from
1 h
Height/depth
45 mm
Length
595 mm
Electric shock protection class
I
Power factor
.95
Maximum power
30 W
Housing material
Steel
Diffuser/lampshade material
Structured plastic
Rated voltage up to
264 V
Rated voltage from
176 V
Rated luminous flux
4600 lm
Current type
Alternating current (AC)
Power supply system
Decentralized (individual battery)
IP protection rating
IP40
Ambient temperature up to
30 °C
Ambient temperature from
0 °C
Battery type (by chemical composition)
Lithium-ion
Lamp type
Non-replaceable LED
Connection diagram type
Maintained
Monitoring device
Test button
Control device
Voltage-controlled LED control gear
Housing color
White
Color temperature at
4000 K
Colour temperature from
4000 K
Lamp base (holder)
No (without)
Width
595 mm
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
