Innolux
LED luminaire 97 186 DVO-09-P-40-3K-IP40-Grigliato-A1 CRI90 Innolux 97186
SKU: 97186
ETIM: EC001957
13143 ₽
Preorder
Construction.
All-metal welded enclosure made of sheet steel, coated with white powder paint. Features a convenient push-in terminal block for connection.
Installation.
Mounted in "Grillato" type suspended ceilings and attached to the ceiling or an опорная surface using hangers.
Optical part.
Prismatic or opal diffusers made of lighting polymer material provide uniform soft light.
Light source.
High-efficiency HONGLI 2835 LEDs with a color rendering index >90 are used.
Areas of use.
Retail halls, public and administrative premises.
Additional information.
The luminaire is equipped with an emergency power supply unit.
| Emergency operating time to | 1 ч |
| Emergency operation time from | 1 ч |
| Height/depth | 45 мм |
| Length | 588 мм |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Power factor | Please provide the text you would like me to translate. Currently, you have only provided ".97". |
| Maximum power | 40 Вт |
| Housing material | Steel |
| Diffuser/lampshade material | Structured plastic |
| Rated voltage up to | 264 В |
| Rated voltage from | 176 В |
| Rated luminous flux | 5900 лм |
| Current type | Alternating current (AC) |
| Power supply system | Decentralized (individual battery) |
| IP protection rating | IP40 |
| Ambient temperature up to | 30 град.C |
| Ambient temperature from | 0 град.C |
| Battery type (by chemical composition) | Lithium-ion |
| Lamp type | Non-replaceable LED |
| Connection diagram type | Maintained |
| Monitoring device | Test button |
| Control device | Voltage-controlled LED control gear |
| Housing color | White |
| Color temperature at | 3000 К |
| Colour temperature from | 3000 К |
| Lamp base (holder) | No (without) |
| Width | 588 мм |
