Varton
Architectural LED luminaire Frieze L 60W 5000K lensed 60deg. RAL7045 gray. VARTON V1-G1-71443-04L07-6606050
SKU: V1-G1-71443-04L07-6606050
ETIM: EC001744
Price on request
Analogues by specifications
The Frieze series of architectural floodlights is designed to solve architectural lighting tasks of any complexity, from facade floodlighting to accent lighting of building details. The floodlight design will fit organically into the architecture of any style. The aluminum body and tempered glass reliably protect the luminaire from external influences. The bracket design allows for precise aiming of the floodlight beam at the required detail of the facade.
Without dimming
Yes
Supplied with lamp
Yes
Outer diameter
268 mm
Height/depth
197 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
268 mm
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
I
Number of poles
3
Power factor
.97
Maximum power
60 W
Housing material
Aluminum
Diffuser/lampshade material
Clear glass
Matt surface
No
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
6000 lm
Rated LED DC current from
1125 mA
Colour uniformity (MacAdam ellipse)
SDCM3
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
No
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
6000 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1 mm²
Connectable conductor cross-section at
1 mm²
Connected conductor cross-section from
1 mm²
Mounting method
Surface mounting
Connection method
Clamp contact
IP protection rating
IP66
Ambient temperature up to
45 °C
Ambient temperature from
-40 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Wide beam 41-80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Color temperature at
5000 K
Colour temperature from
5000 K
Lamp base (holder)
No (without)
Width
268 mm
Luminaire efficiency
100 lm/W
