Varton
LED luminaire Cerberus 75W 5000K IP67 for security perimeter pole mount dimmer DALI RAL9005 black VARTON V1-S1-90658-40D32-6707550
SKU: V1-S1-90658-40D32-6707550
ETIM: EC000062
29,618 ₽
Get back 296 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Cerberus is an outdoor luminaire for perimeter lighting. In Standby mode, it provides illumination of at least 0.5 lx at ground level along the monitored zone. In Alarm mode, it provides illumination of more than 10 lx along a strip at least 3 m wide around the perimeter of the protected zone. The housing is made of anodized aluminum profile. The luminaire uses components from leading global manufacturers of LEDs and electronics, ensuring high reliability and efficiency of the product.
Without dimming
No
Supplied with lamp
Yes
Height/depth
140 мм
Diameter at top section on luminaire side
48 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
Yes
DMX dimming
No
GPRS dimming
No
LineSwitch dimming
No
RF dimming
No
Zigbee dimming
No
Voltage modulation dimming
No
Push-button dimming
No
Trailing-edge phase dimming
No
Leading-edge phase-cut dimming
No
Remote control
Control group
Length
365 мм
Cable length
.4 м
Protective surface coating
Powder-coated
Colour rendering index
70-79 (class 2A)
Electric shock protection class
I
Built-in luminaire energy efficiency class
A++, A+, A (LED)
Number of poles
5
Power factor
.95
Maximum power
75 Вт
Housing material
Aluminum
Diffuser/lampshade material
Transparent plastic
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
9750 лм
Rated LED DC current from
625 мА
Ballast included
Yes
Suitable for upper cut size to
48 мм
Suitable for top-cut size from
40 мм
Suitable for number of light sources
1
Constant luminous flux
Yes
Dimming potentiometer (built-in)
No
Programmable dimming
No
Fire protection "d"
No
Radio-controlled
No
Light distributor
Focusing lens
DSI dimming
No
Adjustable optics
No
Current type
AC/DC
With programmable light control
Yes
With connecting cable
Yes
Touch dimming
No
Core cross-section
.75 кв.мм
Sinusoidal dimming
No
Manufacturer's proprietary dimming system
No
Mounting method
Cantilever
Connection method
Clamp contact
IP protection rating
IP67
Ambient temperature up to
45 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
Black
Light color
White
Colour temperature from
5000 К
Lamp base (holder)
No (without)
Width
265 мм
Luminaire efficiency
130 лм/Вт
