Varton
LED luminaire DL-01 Pro 160mm 20W 4000K CRI90 176x51mm IP65/40 emergency autonomous continuous action with protective silicate glass RAL7045 moiré gray VARTON V1-RF-7R183-10GOA-6502040
SKU: V1-RF-7R183-10GOA-6502040
ETIM: EC001744
Price on request
Analogues by specifications
Dust and moisture-proof round classic recessed luminaires. Painting in any color according to the RAL scale is possible. Used for lighting medical institutions, offices, retail spaces, cafes, and restaurants. Mounting: clamping fastening system. Installed in stretch, gypsum, or slatted ceiling structures. Two types of housing available: recessed and flat.
Without dimming
Yes
Supplied with lamp
Yes
Outer diameter
176 мм
Built-in height/depth
51 мм
Height/depth
51 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
176 мм
Protective surface coating
Powder-coated
Colour rendering index
90-100 (class 1A)
Electric shock protection class
II
Number of poles
3
Power factor
.95
Maximum power
20 Вт
Housing material
Aluminum
Diffuser/lampshade material
Opal glass
Matt surface
Yes
Mounting diameter
160 мм
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
1890 лм
Rated LED DC current from
125 мА
Colour uniformity (MacAdam ellipse)
SDCM3
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
Yes
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1.5 кв.мм
Connected conductor cross-section from
1.5 кв.мм
Mounting method
Recessed
Connection method
Clamp contact
IP protection rating
IP65
Ambient temperature up to
40 град.C
Ambient temperature from
1 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
4000 К
Lamp base (holder)
No (without)
Width
176 мм
Luminaire efficiency
95 лм/Вт
