Varton
LED luminaire DL-Box 12W 4000K 90x90x170 surface mounted RAL9003 white moiré with opal diffuser VARTON V1-R0-00817-20000-2001240
SKU: V1-R0-00817-20000-2001240
ETIM: EC001744
5,421 ₽
Get back 54 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
DL-Box luminaires are an excellent solution for interior lighting where soft and even light is required. The luminaire is designed for mounting on any flat horizontal surface. The housing is made of aluminum and can be painted in any color according to the RAL scale.
Without dimming
Yes
Height/depth
170 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
90 mm
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
II
Number of poles
3
Power factor
.95
Maximum power
12 W
Housing material
Aluminum
Diffuser/lampshade material
Opal plastic
Matt surface
Yes
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
1200 lm
Rated LED DC current from
75 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
1200 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
2.5 mm²
Connected conductor cross-section from
2.5 mm²
Mounting method
Surface mounting
Connection method
Clamp contact
IP protection rating
IP20
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
White
Light color
White
Colour temperature from
4000 K
Lamp base (holder)
No (without)
Width
90 mm
Luminaire efficiency
100 lm/W
