Varton
LED luminaire DL-Box Reflect Multi 1x4 10W 3000K 150x40x150 surface mounted 24deg. RAL7045 grey moire VARTON V1-R0-70253-20L20-2001030
SKU: V1-R0-70253-20L20-2001030
ETIM: EC001744
5,437 ₽
Get back 54 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
DL-Box Reflect - surface-mounted luminaires for interior lighting with various optics. The aluminum profile housing can be painted in any color according to the RAL scale. Used for lighting offices, apartments, hotels, retail spaces, cafes, and restaurants.
Without dimming
Yes
Height/depth
150 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
150 mm
Protective surface coating
Powder-coated
Colour rendering index
90-100 (class 1A)
Electric shock protection class
II
Number of poles
3
Power factor
.95
Maximum power
10 W
Housing material
Aluminum
Matt surface
Yes
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
950 lm
Rated LED DC current from
375 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
White
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
950 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1.5 mm²
Connected conductor cross-section from
1.5 mm²
Mounting method
Surface mounting
Connection method
Pluggable terminal
IP protection rating
IP20
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Medium beam 20-40 deg.
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
3000 K
Lamp base (holder)
No (without)
Width
40 mm
Luminaire efficiency
95 lm/W
