Varton
DL-Box Reflect Multi 1x2 trimless 80x43x63 8W 4000K 55deg. recessed RAL9003 white moiré VARTON V1-R0-00627-20L55-2000840
SKU: V1-R0-00627-20L55-2000840
ETIM: EC001744
3,296 ₽
Get back 32 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
DL-Box Reflect Multi Trimless - trimless recessed luminaires for interior lighting with various optics. Aluminum profile housing. Plaster-in mounting. Luminaires are used for lighting offices, apartments, hotels, retail spaces, cafes, and restaurants.
Without dimming
Yes
Supplied with lamp
Yes
Built-in length
84 mm
Built-in height/depth
63 mm
Height/depth
63 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
80 mm
Protective surface coating
Powder-coated
Colour rendering index
90-100 (class 1A)
Electric shock protection class
II
Number of poles
3
Power factor
.95
Maximum power
8 W
Housing material
Aluminum
Diffuser/lampshade material
No (without)
Matt surface
Yes
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
800 lm
Rated LED DC current from
600 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
White
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
Yes
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1.5 mm²
Connected conductor cross-section from
1.5 mm²
Mounting method
Recessed
Connection method
Pluggable terminal
IP protection rating
IP20
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Wide beam 41-80 deg
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
White
Light color
White
Colour temperature from
4000 K
Lamp base (holder)
No (without)
Width
43 mm
Installation width
44 mm
Luminaire efficiency
100 lm/W
