Varton
DL-Box Reflect Multi 1x4 trimless 150х43х63 8W 3000K 24deg. recessed RAL9003 white VARTON V1-R0-00628-20L20-2001030
SKU: V1-R0-00628-20L20-2001030
ETIM: EC001744
5,179 ₽
Get back 51 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Without dimming
Yes
Supplied with lamp
Yes
Built-in length
154 mm
Built-in height/depth
63 mm
Height/depth
63 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
150 mm
Protective surface coating
Powder-coated
Colour rendering index
90-100 (class 1A)
Electric shock protection class
II
Number of poles
3
Power factor
.95
Maximum power
10 W
Housing material
Aluminum
Diffuser/lampshade material
No (without)
Matt surface
Yes
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
900 lm
Rated LED DC current from
375 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
White
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
Yes
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1.5 mm²
Connected conductor cross-section from
1.5 mm²
Mounting method
Recessed
Connection method
Pluggable terminal
IP protection rating
IP20
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Medium beam 20-40 deg.
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
White
Light color
White
Colour temperature from
3000 K
Lamp base (holder)
No (without)
Width
43 mm
Installation width
44 mm
Luminaire efficiency
90 lm/W
0
★★★★★
