Varton
DL-Grill LED luminaire for Grilliato ceiling 150x150 15W 3000K 140x140x100 IP40 built-in RAL7045 ser. moire dimmer DALI VARTON V1-R0-70809-10D01-4001530
SKU: V1-R0-70809-10D01-4001530
ETIM: EC001744
6,718 ₽
Get back 67 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
DL-Grill luminaires are designed for installation in Grigliato ceilings. Luminaires are used for indoor lighting of office and retail premises, as well as in general-purpose rooms. Thanks to convenient height-adjustable L-shaped mounts, the luminaire is installed in a Grigliato ceiling with a guide height of 30, 40, or 50 mm.
Without dimming
No
Supplied with lamp
Yes
Built-in length
140 mm
Built-in height/depth
100 mm
Height/depth
100 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
Yes
DMX dimming
No
Voltage modulation dimming
No
Length
140 mm
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
II
Number of poles
5
Power factor
.95
Maximum power
15 W
Housing material
Steel
Diffuser/lampshade material
Opal plastic
Matt surface
Yes
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
1400 lm
Rated LED DC current from
94 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
Yes
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
1400 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
2.5 mm²
Connectable conductor cross-section at
2.5 mm²
Connected conductor cross-section from
2.5 mm²
Mounting method
Recessed
Connection method
Clamp contact
IP protection rating
IP40
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Color temperature at
3000 K
Colour temperature from
3000 K
Lamp base (holder)
No (without)
Width
140 mm
Installation width
140 mm
Luminaire efficiency
93 lm/W
