Varton
LED luminaire E070 2.0 35W 4000K CRI90 for educational institutions for Grilyato 588x588x50 opal diffuser VARTON V1-E0-00070-31OP0-4003540
SKU: V1-E0-00070-31OP0-4003540
ETIM: EC002892
6949 ₽
Preorder
E070 2.0 series LED luminaires are an energy-efficient solution for lighting preschool, school, secondary vocational, higher, and other educational institutions. The luminaires are supplied with a diffuser, which simplifies their purchase and operation. The housing is made of solid sheet steel with a white powder coating. The luminaires are mounted in Grille-type ceilings.
| Without dimming | Yes |
| Supplied with lamp | No |
| Can be covered with thermal insulation | No |
| Built-in length | 588 мм |
| Built-in height/depth | 50 мм |
| Height/depth | 50 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | No |
| GPRS dimming | No |
| LineSwitch dimming | No |
| RF dimming | No |
| Zigbee dimming | No |
| Dimming depending on control mechanism | No |
| Voltage modulation dimming | No |
| Push-button dimming | No |
| Trailing-edge phase dimming | No |
| Leading-edge phase-cut dimming | No |
| Length | 588 мм |
| Colour rendering index | 90-100 (class 1A) |
| Grille design | No (without) |
| Glow-wire test in accordance with IEC 60695-2-11 | No (without) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Built-in luminaire energy efficiency class | A++, A+, A (LED) |
| Number of poles | 3 |
| Power factor | .95 |
| Maximum power | 35 Вт |
| Housing material | Steel |
| Diffuser/lampshade material | Opal plastic |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 4200 лм |
| Rated LED DC current from | 82 мА |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | No |
| Suitable for continuous light lines | No |
| Suitable for surface mounting | No |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | Yes |
| Suitable for number of light sources | 1 |
| Suitable for emergency lighting | No |
| Dimming potentiometer (built-in) | No |
| Designed for flush mounting | Yes |
| Programmable dimming | No |
| Fire protection "d" | No |
| Light distributor | Diffuser lens/optics/panel |
| DSI dimming | No |
| Current type | Alternating current (AC) |
| With motion sensor | No |
| With light sensor | No |
| With air circulation opening | No |
| Light output | Straight |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 2.5 кв.мм |
| Sinusoidal dimming | No |
| Manufacturer's proprietary dimming system | No |
| Connection method | Pluggable terminal |
| IP protection rating | IP40 |
| Ambient temperature up to | 40 град.C |
| Ambient temperature from | 1 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Extra wide beam > 80 deg |
| Impact resistance | IK02 |
| Control device | LED current-controlled device |
| Housing color | White |
| Light color | White |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 588 мм |
| Installation width | 588 мм |
| Luminaire efficiency | 120 лм/Вт |
