Varton
Frieze 2.0 S LED luminaire 30W 5000K IP66 60deg. RAL7045 gray dimmer DALI VARTON V1-G1-72441-04D07-6603050
SKU: V1-G1-72441-04D07-6603050
ETIM: EC001744
Price on request
Analogues by specifications
Request a price
Запрос отправлен
We will contact you shortly.
The architectural lighting floodlight is designed to create accent and decorative lighting for buildings and structures. The luminaire is made in a cast aluminum housing with protective tempered glass, ensuring its durability and resistance to external influences. The luminaire is suitable for all types of architectural lighting, including facades, monuments, bridges, and landscape elements. The floodlight is easily mounted on a flat surface and is equipped with an adjustable mechanism that allows for adjusting the tilt angle for precise direction of the light flux. This is a universal solution that guarantees high-quality lighting and reliable protection in all weather conditions.
Without dimming
No
Supplied with lamp
Yes
Height/depth
77 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
Yes
DMX dimming
No
Voltage modulation dimming
No
Length
225 mm
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
I
Number of poles
5
Power factor
.95
Maximum power
30 W
Housing material
Aluminum
Diffuser/lampshade material
Clear glass
Matt surface
No
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
3300 lm
Rated LED DC current from
375 mA
Colour uniformity (MacAdam ellipse)
SDCM3
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
No
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
3300 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1 mm²
Connected conductor cross-section from
1 mm²
Mounting method
Surface mounting
Connection method
Clamp contact
IP protection rating
IP66
Ambient temperature up to
45 °C
Ambient temperature from
-40 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Wide beam 41-80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
5000 K
Lamp base (holder)
No (without)
Width
195 mm
Luminaire efficiency
110 lm/W
