Varton
FLEX 50 modular LED luminaire 50x52 8W 3000K 25deg. IP20 built-in DALI dimmer VARTON V1-R0-00435-10D20-2000830
SKU: V1-R0-00435-10D20-2000830
ETIM: EC001744
6,428 ₽
Get back 64 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
The FLEX 50 modular luminaire series is primarily designed for lighting in the hospitality sector (HORECA). The design of the interchangeable frames takes into account the specifics of use in various rooms. Swivel and fixed frames are available with different rotation radii and degrees of LED module recess relative to the outer surface of the frame. The deepest versions are suitable for rooms requiring soft and dimmed light.
Without dimming
No
Supplied with lamp
Yes
Outer diameter
50 mm
Built-in height/depth
52 mm
Height/depth
52 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
Yes
DMX dimming
No
Voltage modulation dimming
No
Length
50 mm
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
II
Number of poles
5
Power factor
.9
Maximum power
8 W
Housing material
Aluminum
Diffuser/lampshade material
Transparent plastic
Matt surface
No
Mounting diameter
50 mm
Rated voltage up to
230 V
Rated voltage from
220 V
Rated luminous flux
750 lm
Rated LED DC current from
0 mA
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
Yes
Programmable dimming
No
Current type
Alternating current (AC)
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
750 lm
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1.5 mm²
Connectable conductor cross-section at
1.5 mm²
Connected conductor cross-section from
1.5 mm²
Mounting method
Recessed
Connection method
Clamp contact
IP protection rating
IP20
Ambient temperature up to
40 °C
Ambient temperature from
1 °C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Medium beam 20-40 deg.
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
Black
Light color
White
Color temperature at
3000 K
Colour temperature from
3000 K
Lamp base (holder)
No (without)
Width
50 mm
Luminaire efficiency
94 lm/W
