LED luminaire Olymp 2.0 150W 5000K IP65 60deg. industrial MAXI dimmer DALI VARTON V1-I0-7M603-04D07-6515050
SKU: V1-I0-7M603-04D07-6515050
ETIM: EC001744
55370 ₽
Preorder
The high-efficiency second-generation Olymp 2.0 LED luminaire is designed for use in industrial and wet environments. For mounting on walls, ceilings, or floors, the luminaire is equipped with a swivel bracket with an adjustable tilt angle within 180 degrees. The luminaire housing is made of anodized aluminum profile. To protect the LEDs, secondary optics made of PMMA, resistant to physical and chemical influences, is used. The modular design of the product combined with high energy efficiency makes it a worthy successor to classic industrial products.
| Without dimming | No |
| Supplied with lamp | Yes |
| Height/depth | 165 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | Yes |
| DMX dimming | No |
| Voltage modulation dimming | No |
| Length | 360 мм |
| Colour rendering index | 70-79 (class 2A) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Number of poles | 5 |
| Power factor | .95 |
| Maximum power | 150 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Transparent plastic |
| Matt surface | No |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 23850 лм |
| Rated LED DC current from | 313 мА |
| Colour uniformity (MacAdam ellipse) | SDCM5 |
| Reflector | No (without) |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 1 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | No |
| Programmable dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| Light output | Straight |
| Luminous flux from | 23850 лм |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 1 кв.мм |
| Connected conductor cross-section from | 1 кв.мм |
| Mounting method | Surface mounting |
| IP protection rating | IP65 |
| Ambient temperature up to | 45 град.C |
| Ambient temperature from | -40 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Wide beam 41-80 deg |
| Impact resistance | IK01 |
| Control device | LED current-controlled device |
| Housing color | Grey |
| Light color | White |
| Colour temperature from | 5000 К |
| Lamp base (holder) | No (without) |
| Width | 275 мм |
| Luminaire efficiency | 159 лм/Вт |
