Diora
LED luminaire Piton 2Ex 20/2200 D opal 2200lm 20W 5000K IP65 0.95PF 80Ra Kp<1 transit Diora DP2Ex20-D-O-5K-T
SKU: DP2Ex20-D-O-5K-T
ETIM: EC001952
15,836 ₽
Get back 158 ₽ in points
Analogues by specifications
Explosion protection level 2Ex — use in zones of class 2 for gas, 22 for dust
Explosion protection marking 2Ex nA IIC T6 Gc
High IP65 protection degree
Operating temperature range -40..55 °C
Enclosed dust-proof housing
Transit version
Supplied with lamp
Yes
Height/depth
59 мм
Length
340 мм
For gas explosion hazardous areas
2
For dust explosion protection zone (EU ATEX directives)
22
Electric shock protection class
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Number of poles
3
Power factor
.95
Maximum power
20 Вт
Housing material
Aluminum
Diffuser/lampshade material
Structured plastic
Rated voltage from
220 В
Rated luminous flux
2200 лм
Rated LED DC current from
700 мА
Ballast included
Yes
Suitable for lamp power from
20 Вт
Suitable for number of light sources
1
Adjustable
Yes
Current type
AC/DC
Core cross-section
1 кв.мм
Mounting method
Wall/Ceiling
Connection method
Screw terminal
IP protection rating
IP65
Ambient temperature up to
55 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Suitable for through-wiring
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK05
Control device
LED current-controlled device
Light color
White
Color temperature at
5000 К
Colour temperature from
5000 К
Lamp base (holder)
No (without)
Width
75 мм
