Diora
LED luminaire Piton 2Ex 20/2600 G90 2600lm 20W 4000K IP65 0.95PF 80Ra $\eta$<1 emergency Diora DP2Ex20-G90-4K-A
SKU: DP2Ex20-G90-4K-A
ETIM: EC001952
26210 ₽
Preorder
Аварийное исполнение
Уровень взрывозащиты 2Ex — использование в зонах классов 2 по газу, 22 по пыли
Маркировка взрывозащиты 2Ex nA IIC Т6 Gc X
Высокая степень защиты IP65
Диапазон рабочих температур 5..40 °C
Закрытый пылезащищенный корпус
| Supplied with lamp | Yes |
| Height/depth | 59 мм |
| Length | 320 мм |
| For gas explosion hazardous areas | 2 |
| For dust explosion protection zone (EU ATEX directives) | 22 |
| Electric shock protection class | I |
| Number of poles | 4 |
| Power factor | .95 |
| Maximum power | 20 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Structured plastic |
| Rated voltage from | 220 В |
| Rated luminous flux | 2600 лм |
| Rated LED DC current from | 700 мА |
| Ballast included | Yes |
| Suitable for lamp power from | 20 Вт |
| Suitable for number of light sources | 1 |
| Adjustable | Yes |
| Current type | AC/DC |
| Core cross-section | 1 кв.мм |
| Mounting method | Wall/Ceiling |
| Connection method | Screw terminal |
| IP protection rating | IP65 |
| Ambient temperature up to | 55 град.C |
| Ambient temperature from | 5 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Extra wide beam > 80 deg |
| Impact resistance | IK05 |
| Control device | LED current-controlled device |
| Light color | White |
| Color temperature at | 4000 К |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 75 мм |
