Diora
LED luminaire Piton 2Ex 56/6900 D clear 6900lm 56W 5000K IP65 0.95PF 80Ra Rf<1 Diora DP2Ex56-D-PZ-5K
SKU: DP2Ex56-D-PZ-5K
ETIM: EC001952
18,377 ₽
Get back 183 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Explosion protection level 2Ex — use in class 2 gas zones, 22 dust zones
Explosion protection marking 2Ex nA IIC T6 Gc X
High IP65 protection rating
Operating temperature range -40..55 °C
Enclosed dust-proof housing
Supplied with lamp
Yes
Height/depth
59 мм
Length
620 мм
For gas explosion hazardous areas
2
For dust explosion protection zone (EU ATEX directives)
22
Electric shock protection class
I
Number of poles
3
Power factor
.95
Maximum power
56 Вт
Housing material
Aluminum
Diffuser/lampshade material
Structured plastic
Rated voltage from
220 В
Rated luminous flux
6900 лм
Rated LED DC current from
700 мА
Ballast included
Yes
Suitable for lamp power from
56 Вт
Suitable for number of light sources
1
Adjustable
Yes
Current type
AC/DC
Core cross-section
1 кв.мм
Mounting method
Wall/Ceiling
Connection method
Screw terminal
IP protection rating
IP65
Ambient temperature up to
55 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK05
Control device
LED current-controlled device
Light color
White
Color temperature at
5000 К
Colour temperature from
5000 К
Lamp base (holder)
No (without)
Width
75 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
