Unit DC Ex 75/8500 D120 8500lm 75W 3000K IP66 70Ra Cp<1 console Diora DUDCEx75D120-3K-C

Diora

Unit DC Ex 75/8500 D120 8500lm 75W 3000K IP66 70Ra Cp<1 console Diora DUDCEx75D120-3K-C

SKU: DUDCEx75D120-3K-C ETIM: EC001952

84,555 ₽

Get back 845 ₽ in points

Description Specifications Reviews

Supplied with lamp Yes

Height/depth 110 мм

Length 432 мм

For gas explosion hazardous areas 1, 2

For dust explosion protection zone (EU ATEX directives) 21, 22

Electric shock protection class III

Number of poles 2

Power factor .98

Housing material Aluminum

Diffuser/lampshade material Structured plastic

Rated voltage from 24 В

Rated luminous flux 8500 лм

Rated LED DC current from 700 мА

Ballast included Yes

Suitable for lamp power from 75 Вт

Suitable for number of light sources 1

Current type Direct current (DC)

Core cross-section 1 кв.мм

Mounting method Wall mount

Connection method Screw terminal

IP protection rating IP66

Ambient temperature up to 40 град.C

Ambient temperature from -60 град.C

Lamp type Non-replaceable LED

Connection type Suitable for through-wiring

Light beam angle Extra wide beam > 80 deg

Impact resistance IK08

Control device LED current-controlled device

Light color White

Color temperature at 3000 К

Colour temperature from 3000 К

Lamp base (holder) No (without)

Width 165 мм
