Varton
LED luminaire C070/U 45W 4000K CRI90 IP54 595x595x68 medical recessed/surface mounted opal diffuser VARTON V1-C0-00080-20000-5405440
SKU: V1-C0-00080-20000-5405440
ETIM: EC002892
13,480 ₽
Get back 134 ₽ in points
Analogues by specifications
The C070/U LED luminaire is an energy-efficient replacement for fluorescent lamps and is intended for lighting clean rooms and cafeterias in medical institutions. It features an all-metal welded body made of sheet steel with a white powder coating. To ensure the degree of protection, a silicone seal is fixed around the perimeter of the body. The luminaire is designed for installation in Armstrong-type suspended ceilings or mounted on a flat surface.
Without dimming
Yes
Supplied with lamp
Yes
Can be covered with thermal insulation
No
Built-in length
595 мм
Built-in height/depth
68 мм
Height/depth
68 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
GPRS dimming
No
LineSwitch dimming
No
RF dimming
No
Zigbee dimming
No
Dimming depending on control mechanism
No
Voltage modulation dimming
No
Push-button dimming
No
Trailing-edge phase dimming
No
Leading-edge phase-cut dimming
No
Length
595 мм
Colour rendering index
90-100 (class 1A)
Grille design
No (without)
Glow-wire test in accordance with IEC 60695-2-11
No (without)
Electric shock protection class
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Built-in luminaire energy efficiency class
A++, A+, A (LED)
Number of poles
3
Power factor
.95
Maximum power
45 Вт
Housing material
Steel
Diffuser/lampshade material
Opal plastic
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
5400 лм
Rated LED DC current from
141 мА
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Suitable for continuous light lines
No
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
Yes
Suitable for number of light sources
1
Suitable for emergency lighting
No
Dimming potentiometer (built-in)
No
Designed for flush mounting
Yes
Programmable dimming
No
Fire protection "d"
No
Light distributor
Diffuser lens/optics/panel
DSI dimming
No
Current type
AC/DC
With motion sensor
No
With light sensor
No
With air circulation opening
No
Light output
Straight
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
2.5 кв.мм
Sinusoidal dimming
No
Manufacturer's proprietary dimming system
No
Connection method
Clamp contact
Old URL
https://sissol.ru/shop/58941-svetodiodnyj-svetilnik-varton-ip54-medicinskij-nakladnoj-59559555-mm-s-opalovym-rasseivatelem-54-vt-4000k.html
IP protection rating
IP54
Ambient temperature up to
40 град.C
Ambient temperature from
-20 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Extra wide beam > 80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
White
Light color
White
Color temperature at
4000 К
Colour temperature from
4000 К
Lamp base (holder)
No (without)
Width
595 мм
Installation width
595 мм
Luminaire efficiency
120 лм/Вт
