Universal cable tester RJ-45+RJ-11+RJ-12+USB+BNC (HT-2468B) REXANT 12-1003

Universal cable tester RJ-45 + RJ-11/RJ-12 + 1394 + USB + BNC 3468 REXANT is used for testing twisted pair, telephone, USB, and coaxial cables. The tester consists of two functional units — an active part and a passive part (plug) — which connect to the ends of the cable line via RJ-45, RJ-11/RJ-12, 1394, USB, and BNC connectors. The device features a built-in 25/50 Ohm BNC terminator. Test results are displayed on an informative LED panel, which also includes a battery charge indicator. The housing is made of impact-resistant plastic and has a stylish, practical design. Specifications: Tests twisted pair cables, telephone cables, coaxial cables with BNC female connectors, USB cables with Type A on one end and Type B on the other end, and 1394 cables with Type i connectors on both ends. Audio and visual event indication Low battery indication Maximum tested cable length: 200 m Size: 144x86x25.5 mm Weight: 128 g Battery: 9V Alkaline (6F 22) (not included) Package contents: cable tester, pouch, manual.
