Digital socket voltage relay MRVs-16 is designed to automatically disconnect the load connected through it if the voltage value in the power grid exceeds the set limits. The device is controlled by a microcontroller that analyzes the voltage in the power grid and displays its effective value on a digital indicator. Load switching is carried out by an electromagnetic relay. The permissible disconnection limits and the turn-on delay time are set by the user using buttons. Values are saved in non-volatile memory.
Advantages of the MRVs-16 EKF PROxima digital socket voltage relay:
• Minimum and maximum voltage limits can be set.
• Manual on/off via button.
• Designed for switching a current of 16 A.
Voltage value is displayed on an electronic display
1-phase
Yes
3-phase
No
1-phase hysteresis monitoring possible
Yes
1-phase undervoltage monitoring possible
Yes
3-phase hysteresis monitoring possible
No
3-phase undervoltage monitoring possible
No
Height
43 мм
Height
43 мм
Depth
120 мм
Voltage measurement range 1 at
210 В
Voltage measurement range 1 from
120...210 В
Voltage measuring range 2 to
280 В
Voltage measuring range 2 from
220...300 В
Number of normally closed (NC) contacts
0
Number of normally open (NO) contacts
1
Number of switching contacts
0
Maximum permissible delay time
0.5 с
Maximum permissible trip delay time without holding
600 с
Minimum adjustable delay time
0.02 с
Minimum adjustable response delay time without time lag
5 с
Rated control supply voltage Us AC at 50 Hz up to
400 В
Rated control supply voltage Us AC at 50 Hz from
60...300 В
Rated control circuit AC supply voltage Us at 60 Hz from
100...400 В
Rated control supply voltage Us DC up to
0 В
Rated control supply voltage Us DC from
0 В
Rated switching current
16 А
Tripping threshold voltage to
280 В
Response threshold voltage from
160...280 В
Switch-on current type
AC (alternating)
Monitored voltage current type
AC (alternating)
With removable terminals, clamps
No
Includes DC voltage monitoring functions - hysteresis
No
Includes DC voltage monitoring functions - overvoltage
No
Includes DC voltage monitoring functions - undervoltage
No
Connection type
Plug-in connection
Width
54 мм
