ATS device MCB 20A (C) 3P 400V EKF PROxima ats-mcb-20c-3p-pro
SKU: ats-mcb-20c-3p-pro
ETIM: EC012357
8,753 ₽
Get back 87 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
EKF ATS device is designed to provide backup power supply to a load connected to a power supply system that has a main and a backup input. The ATS device automatically connects the backup power line in case of voltage loss on the main line. Designed for three-phase four-wire (or single-phase single-wire) dual AC power supply systems with a frequency of 50/60 Hz, rated voltage 400 V/230 V and rated current up to 63A. The device is made in the form of a monoblock and consists of a control unit and two modular circuit breakers. The control unit has a manual override lever. This design allows for reduced dimensions and installation area of the ATS.
Standby contact closing time
0...30 ms
Main supply contact opening time
0...30 ms
Height
135 mm
Height
135 mm
Depth
118 mm
Number of inputs
2
Number of outputs
1
Number of poles
3
Number of input phases
3
Number of output phases
3
Modular design
No
Rated input voltage
400 V
Rated AC voltage 50 Hz
400 V
Generator rated input current
20 A
Rated input current from external fixed mains
20 A
Rated current
20 A
Breaking capacity in accordance with IEC947, Icu, 400 V
4.5 kA
With overheating protection
Yes
With LED display
Yes
With earth fault protection function
No
IP protection rating
IP20
Operating temperature from
-40...50 °C
Residual current device (RCD)
No
Overload protection device to
20 A
Overload protection device from
20 A
Frequency (Hz)
50/60 Hz
Width
185 mm
