Residual current device (RCD) KARAT VD3-63 4P 63A 30mA 6kA type AC IEK MDV20-4-063-030
SKU: MDV20-4-063-030
ETIM: EC000003
2,396 ₽
Get back 23 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
The differential current circuit breaker without built-in overcurrent protection, type VD3-63 series KARAT, is designed to automatically disconnect power in case of insulation failure in single-phase and three-phase AC electrical circuits with a rated voltage of up to 400 V and a frequency of 50 Hz.
The circuit breaker is electromechanical and is functionally independent of the mains voltage; it is intended for use in residential, public, and industrial facilities, construction sites, and is installed in low-voltage switchgear and distribution units with an ingress protection rating of at least IP30.
The RCD is not intended to disconnect short-circuit currents and overload currents.
Number of poles
4
Maximum supply cable cross-section
50 кв.мм
Mech. endurance
10000
Tightening torque from
2 Н·м
Rated impulse withstand voltage
6
Rated non-tripping residual current
15.0
Rated leakage current
0.03
Rated conditional short-circuit current Icn
6000
Rated ultimate breaking capacity (Icw)
6 кА
Rated voltage
400 В
Rated insulation voltage Ui
415 В
Rated current
63 А
Rated current
63 А
Rated leakage current
.03 мА
Shunt rated current
63 А
Ambient operating temperature to
45 град.C
Ambient operating temperature from
-25...45 град.C
Operating mode
Continuous-S1
Selective protection
No
Flexible stranded conductor cross-section up to
35 кв.мм
Stranded flexible conductor cross-section from
1.5...35 кв.мм
Solid conductor cross-section to
50 кв.мм
Solid conductor cross-section from
1.5...50 кв.мм
Mounting method
On DIN rail
IP protection rating
IP20
Residual current type
Alternating current (AC)
Conditional rated residual short-circuit current
6
Resistance to current surges
- кА
Frequency
50/60 Hz Гц
Frequency (Hz)
50/60 Hz
Width in modular units
4
Electrical endurance
4000
