IEK
Residual Current Circuit Breaker (RCCB) VD1-63S 4P 32A 100mA IEK MDV12-4-032-100
SKU: MDV12-4-032-100
ETIM: EC000003
3,796 ₽
Get back 37 ₽ in points
Analogues by specifications
Stock by warehouse
Residual current circuit breakers, non-magnetic, without overcurrent protection, functionally independent of mains voltage, for domestic or similar applications, disconnection time type VD1-63S, are designed for automatic power disconnection in case of differential leakage currents in single-phase and three-phase AC electrical networks with a rated voltage of up to 400V.
VD1-63S are intended for installation in low-voltage complex input and distribution devices operated in residential, public, and industrial facilities, as well as construction sites.
Additional equipment possible
No
Mounting installation depth
74.0 мм
Number of poles
4
Maximum supply cable cross-section
50 кв.мм
Rated impulse withstand voltage
6
Rated leakage current
0.10
Rated ultimate breaking capacity (Icw)
6 кА
Rated voltage
400 В
Rated current
32 А
Rated current
32 А
Rated leakage current
Please provide the text you would like me to translate. мА
With short-time delayed tripping
Yes
Selective protection
Yes
Mounting method
On DIN rail
IP protection rating
IP20
Residual current type
Alternating current (AC)
Conditional rated residual short-circuit current
6
Conditional rated short-circuit current Iq
6 кА
Resistance to current surges
0.25 кА
Frequency
50 Hz Гц
Frequency (Hz)
50 Hz
Width in modular units
4
