Analogues by specifications
EBM16FU30 Metal enclosure with plug, 16 poles, 16A, top entry (PG 21), IP65
TECHNICAL INFORMATION
Rated current 16A
Number of poles 16
Utilization category AC15
Mechanical service life (minimum)? 500
Electrical service life (minimum)? 100
Rated insulation voltage (Ui) 690V
Rated impulse withstand voltage (Uimp) 6kV
Dielectric strength (contact with body) 1890 V AC
Dielectric strength (contact-contact) 3000 V AC
Insulation resistance 10 MΩ min. (500 V DC)
Operating Temperature -40 / +125 °C
Pollution degree 3
Protection class IP65
Enclosure material Metal
Full description
• Wide product range
• IP65 in closed position
• Universal inserts
• Easy cable routing
• Various lock types
• Metal enclosure with powder coating
Height
76 мм
Depth
0 мм
Length
76 мм
Contact design
Pin
Number of plug-in contacts
16
Number of cable entries
1
Number of poles
16
Number of rows of plug-in contacts
2
Housing insulation material
Polybutylene terephthalate
Contact material
Brass
Housing material
Steel
Contact surface coating material
Silver
Locking mechanism
Latch
Rated impulse voltage
6 кВ
Rated voltage
690 В
Rated current In
16 А
Housing coating
Powder-coated
Housing coating
Powder-coated
Operating temperature
125 град.C
Operating temperature from
-40 град.C
Cable entry position
Top
With protective conductor
No
With seal
Yes
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
.5 кв.мм
Solid conductor cross-section to
2.5 кв.мм
Solid conductor cross-section from
.5 кв.мм
Mounting method
Surface mounting
Assembled IP protection rating
IP65
Connection type
Screw connection
Impact resistance
IK10
Width
93.5 мм
EMC-compatible version
No
